Specification:
8/16/24 Zones
Power Supply:AC85V-264V / 50-60Hz Power: <20W
Working temperature:-20ºC–+50ºC Working Frequency :4KHZ-8KHZ
Parameters :
| Detecting zone: | 8/16/24 zones |
| Display way: | 7 inch color LCD screen |
| Sensitivity: | 0-999 adjustable |
| Detecting speed: | up to 100 passenger/ min. |
| Working temperature: | -20ºC–+50ºC |
| PASS and ALARM count: | up to 99999 |
| Gross weight: | 67KG |
| Warranty: | 2 years |
| Standard External size: | 2200mm(H)X800mm(W)X580mm(D) |
| Standard Internal size: | 2010mm(H)X700mm(W)X500mm(D) |
| Package size for door panels: | 2260*650*260mm *1ctn |
| Package size for control unit: | 780*390*250 mm*1ctn |
