General Specifications:
| Tunnel Size : | 500 (W) ×300 (H) mm |
| Conveyor Speed: | 0.22m/s |
| Conveyor Max Load: | 150kg |
| Single inspection dosage: | <1.01μG |
| Film Safety: | Guarantee ISO1600 Film |
| Leakage radiation: | <0.1µGy/h |
| Steel Penetration: | 36mm |
| Spatial Resolution: | 1.0mm Horizontal and Vertical |
| Wire Resolution: | 40AWG |
| Power Requirement: | 220V AC (±10%) 50±3Hz |
X-RAY GENERATOR:
| Orientation: | Upward |
| Tube Current: | 0.4 to 0.7mA(adjustable) |
| Anode Voltage: | 80KV-140KV(adjustable) |
| Angle: | 80° |
| Generator cooling/working periods: | Sealed oil bath with forced air/100% |
OPERATING ENVIRONMENT:
| Storage Temperature: | -20oC to 60oC |
| Operating Temperature: | 0oC to 45oC |
| Relative Humidity: | 20 to 95% non-condensing |
| System Power: | 220 VAC (±10%) 50±3HZ |
| Power wastage: | 1.0 KW (Max) |
| Noise: | <65DB |
