General Specifications:

Tunnel Size : 650 (W) ×500 (H) mm
Conveyor Speed: 0.22m/s
Conveyor Max Load: 200kg
Single inspection dosage: <1.01μG
Film Safety: Guarantee ISO1600 Film
Leakage radiation: <0.1µGy/h
Steel Penetration: 36mm
Spatial Resolution: 1.0mm Horizontal and Vertical
Wire Resolution: 38AWG
Power Requirement: 220V AC (±10%) 50±3Hz
